The MasterBox NR200P uses features normally found in stylish, high-end ATX cases and cleverly utilizes space-saving measures to create a chassis taking up less than half the volume. Every feature is thoughtfully laid out in an 18-liter space to maximize component compatibility, thermal efficiency, and ease of assembly.

SIZE Mini ITX
AVAILABLE COLOR(S) White
MATERIALS Steel, Plastic, Mesh, Tempered Glass
DIMENSIONS (L X W X H) 376 x 185 x 292mm incl. Protrusions, 360 x 185 x 274mm excl. Protrusions
VOLUME (EXLC. PROTRUSIONS) 18.25L
MOTHERBOARD SUPPORT Mini DTX, Mini ITX, Max MB size: 244 x 226mm (L x H)
EXPANSION SLOTS 3
5.25" DRIVE BAYS 0
3.5" DRIVE BAYS 1 (Max. 2)
2.5" / 3.5" DRIVE BAYS (COMBO) 1
2.5" DRIVE BAYS 2 (Max. 3)
I/O PANEL 2x USB 3.2 Gen 1 Type-A, 1x 3.5mm Headset Jack (Audio+Mic)
PRE-INSTALLED FANS - TOP 2x 120mm 650-1800RPM PWM (SickleFlow)
PRE-INSTALLED FANS - FRONT N/A
PRE-INSTALLED FANS - REAR N/A
PRE-INSTALLED FANS - BOTTOM N/A
FAN SUPPORT - TOP 2x 120mm
FAN SUPPORT - REAR 1x 92mm
FAN SUPPORT - BOTTOM 2x 120mm (recommended slim fans for GPUs wider than 2.5 PCI slots)
FAN SUPPORT - SIDE 2x 120/140mm
RADIATOR SUPPORT - TOP N/A
RADIATOR SUPPORT - REAR 92mm (not compatible with vertical GPU installation)
RADIATOR SUPPORT - BOTTOM 120mm, 240mm, (recommended for custom loops only)
RADIATOR SUPPORT - SIDE 120mm, 140mm, 240mm, 280mm, (not compatible with vertical GPU installation)
CLEARANCE - CPU COOLER 76mm (GPU in vertical position), 153mm (tempered glass side panel), 155mm (vented steel side panel)
CLEARANCE - PSU 130mm
CLEARANCE - GFX L: 330mm (incl. power connector), H: 156mm (incl. power connector), W: 60mm (triple slot)
DUST FILTERS Top, Bottom, Left side, Right side
POWER SUPPLY SUPPORT SFX, SFX-L
WARRANTY 2 years
WEIGHT 5.93 kg
ACCESSORIES 1x PCIe 3.0 x16 riser cable

NOTE
Single slot water-cooler GPUs or vertically mounted GPUs are recommended when using bottom radiator position, This product is only compatible for devices that support the PCI-E 3.0 specification. If you use this product with a motherboard that supports PCI-E 4.0, please enter into BIOS option and select PCI-E 3.0 before installation.
